collector feedback biasing in Hindi | collector feedback biasing with example | collector feedback скачать в хорошем качестве

collector feedback biasing in Hindi | collector feedback biasing with example | collector feedback

collector feedback biasing | dc feedback bias . in this video the collector feedback bias configuration of the bjt is explained beautifully. collector feedback biasing in Hindi | collector feedback biasing with example | collector feedback collector feedback biasing in Hindi collector feedback biasing with example | collector feedback by watching this video you will learn the following topics. dc analysis of collector feedback bias. This self biasing collector feedback configuration is another beta dependent biasing method which requires two resistors to provide the necessary DC bias for the transistor. The collector to base feedback configuration ensures that the transistor is always biased in the active region regardless of the value of Beta (β). The DC base bias voltage is derived from the collector voltage VC, thus providing good stability. In this circuit, the base bias resistor, RB is connected to the transistors collector C, instead of to the supply voltage rail, Vcc. Now if the collector current increases, the collector voltage drops, reducing the base drive and thereby automatically reducing the collector current to keep the transistors Q-point fixed.  Transistor Biasing with Collector-Feedback Resistor This method has a resistor at the base such that one end of it is connected to the terminal base whereas the other end will be connected to the collector. The value of the zero signal of the current at the base can be determined by the voltage applied at the junction in between the terminals collector and base (VCB) instead of VCC. Due to VCB, the junction at the base-emitter gets forward-biased. #collectorfeedbackbias
