SMART 110 Commuter Train North | Grant Ave. Railroad Crossing, Novato CA

Feb 18, 2025 8:07am I started my SMART train adventure 3 here in Novato CA starting here at Grant Ave and I proceeded south towards San Rafael each catch this day. This is a crossing I've wanted to film for a while here and was finally able to get out to it as this is a sideways cantilever crossing and SMART crossing that still features dual Safetran Mechanical Bells on the former NWP 70s era signals that remain here. Back when this crossing was owned by the NWP, The lights were originally 8 inch and 7 inch gate lights, and old 70s stub masts with Safetran Mechanisms later this became an abandoned crossing with it's gates removed but then the NWP came back to this crossing and changed equipment to 12 inch LED Lights and 4 inch incandescents gate lights and reinstalled the gates in the early 2010s. When SMART took over ownership of the crossing in the mid 2010s, they replaced the stubbed masts and Safetran Mechanisms with their gated mast Invensys Rail install long masts and new 7 inch gate lights and also added an exit quad gate for their original design for this crossing keeping the NWP equipment at this crossing on the cantilevers. SMART in the early 2020s would then come back to add onto this crossing when the infill station was added to the system here at the Novato Downtown Station. Pedestrian Signals were added and a pair of back side lights were added onto the quad exit gate and 7 inch gate lights were replaced separately each. Note also the pedestrian signals were installed with WCH E-Bells originally at the top and SMART decided to replace them with GS Type 3s at the side. As you see, the pedestrian gates deactivate before the roadway signals which is a typical SMART setup function. Sonoma Marin Area Rail Transit Commuter Train Northbound on the SMART Line passes through the Grant Avenue railroad crossing in Novato, California. SMART 110 SMART 109 Crossing Info City: Novato, California Line/Crossing Owner: Sonoma Marin Area Rail Transit Line User: SMART Bell Sequence: Ring till gates start rising Right Shoulder Signal - Harmon 70s Cantilever Bell: Safetran Mechanical Bell Lights: 4 pairs of 12x24 inch GE Harmon Fading LEDs/Harmon Lights (90s & Present Style) Junction Boxes: Harmon (70s Style) Cantilever Install: NWP 1970s, Installed between 1974 - 1978 Gated Mast Gate Lights: NEG Clear Gate LEDs "Alstom-Aurora Style" Mechanism/Counterweight Arms: Invensys Rail Base: Safetran Gate Mast Install: SMART early 2010s, Installed 2015 Close Pedestrian Signal Bell: GS Type 3 E-Bell Lights: 2 pairs of 12x24 inch GE Fading LEDs/WCH Lights (Flat) Junction Box: Progress Rail Gate Lights: NEG Gate LEDs Mechanism/Counterweight Arms: WCH Base: Progress Rail Install: SMART early 2020s Left Shoulder Signal - Harmon 70s Cantilever Bell: Safetran Mechanical Bell Lights: 5 pairs of 12x24 inch GE Harmon Fading LEDs/Harmon Lights (90s & Present Style) Junction Boxes: Harmon (70s Style) Cantilever Install: NWP 1970s, Installed between 1974 - 1978 Gated Mast Gate Lights: NEG Clear Gate LEDs "Alstom-Aurora Style" Mechanism/Counterweight Arms: Invensys Rail Base: Safetran Gate Mast Install: SMART early 2010s, Installed 2015 Quad Exit Gate Lights: 2 pairs = Front - 1 pair of GE Fading LEDs/WCH Lights, Back - 1 pair of 12x24 inch WCH 2nd Gen Miller Ingenuity LEDs/Rebel Railway Supply Company (RRSC) Lights Junction Box: Progress Rail Gate Lights: NEG Gate LEDs Mechanism/Counterweight Arms: Invensys Rail Base: Safetran Install: SMART early 2010s, Installed 2015 Far Pedestrian Signal Bell: GS Type 3 E-Bell Lights: 2 pairs of 12x24 inch GE Fading LEDs/WCH Lights (Flat) Junction Box: Progress Rail Gate Lights: NEG Gate LEDs Mechanism/Counterweight Arms: WCH Base: Progress Rail Install: SMART early 2020s This crossing owned by the Sonoma Marin Area Rail Transit is an mixed install with the cantilevers being an NWP 1970s signal install with changes overtime to the lights and light heads. The cantilever gated masts and quad exit gate are SMART early 2010s signal installs but installed in the mid 2010s with gate and gate lights changed overtime and also added back side lights to the quad exit signal. The pedestrian signals are a SMART early 2020s signal install with its bells changed and the positions. Camera Sony FX30 Cinema Line + Tamron 17mm - 300mm Sony Cybershot RX10 IV (Approach)
